bogie testing plants

Derailing safety, riding quality, wear-and-tear behavior...

.. are primarily determined by wheel-load differences on the vehicle and the bogies. For being able to meet tolerance requirements set forth in the regulations for wheel load differences for the whole vehicle, it is first necessary to check the bogies for minimal wheel load differences and eliminate impermissible deviations by adjustment of the spring pre stressing ...
more

stationary wheel load measurement systems

The system PRODAT RL consists of three different models to statically and dynamically measure wheel and axle loads. PRODAT as an independent supplier of complete system solutions is able to cover every usecase in practice. The construction deserves special attention because in difference to other systems there are just minor interventions at the rail track necessary whereas the system features high accuracy/percision and small dimensions ...
more

mobile wheel load measurement systems

The mobile wheel load measurement system PRODAT RL mobil was developed for static measurements at rail cars. In difference the PRODATs stationary plants the mobile system combines requierements of mobility, accurarcy and norms as well as standards (e.g. DIN/EN) our mobile solution is made for out of house control and adjustment measurements ...
more

conveyer belt scales

Conveyer belt scales PRODAT BW, operated in several brown coal opencast mining facilities throughout Germany, can be installed at any position in horizontal and sloping conveyer belts in addition is a modernization of existing facilities possible. The advantages of the belt scales PRODAT BW are their simple construction and easy installation possibilities. The system is very robust and has no parts that can wear out. Therefore maintenance work is reduced to visual and checking controls ...
more

sensor networs (wirebased/wireless/mixed)

As supplier of fully automated measurement systems PRODAT can use it's experience also in the realization of application specific sensor networks. Work proof is PRODATs ZK1000 monitoring the canal bridge at the waterway junction Magdeburg. A large number of critical values (temperature, force, glide and tip gap, ...) is monitored and continueslly collected...
more

wheel load gauging

PRODAT, participating in a long year foreign joint venture, offers rail scale systems labeled PRODAT CE. These scales are suited for determination of weight in rail way good transportation. The series PRODAT CE is certified according to OIML R 106 and OIML class III. PRODAT covers all possible application cases in the area of weight determination. The model PRODAT CE-VK is a static rail scale weighing rail railed motionless vehicles. Model PRODAT CE-VD, conceived for in-motion measurements, features high accuracy and is highly qualified for fast weighing of clutched vehicles. ...
more

bogie test plant retrofitting

By PRODATs many individual projects there was the necessessity of own hardware and electronic solutions. PRODAT also offers the service for its existing and potential new customers first of all in the development of new systems but also when existing plants need a retrofitting...
more

brake force measurment

PRODAT brake force measurment service using PRODAT BKM solution is essential for many railway retroffiting processes ...
more

wheel load measurement

Wheel load measurements using PRODAT RL mobil right at your repair shop or factories ...
more

software development

Since formation PRODAT develops in this product branch custom-designed software. It has extensive experience in the areas of real time operation system development, compiler building, porting and software design. PRODAT uses always the newest development environments and tools to find fast, efficient cost effective solutions. Development and implementation accord to certified methods...
more

electronic and hardware design

Thru PRODATs many individual projects there was the necessessity of own hardware and electronic solutions. PRODAT also offers the service for its existing and potential new customers first of all in the development of new systems but also when existing plants need a retrofitting ...
more

Finished research & development project (KMU)

Finished research and development KMU project ID=80128727
Topic: Development and introduction of a system for wear and tear measurement on the wheel-rail system.
This project was supported through funds of the ministery of economy of the state of Brandenburg and the EU.
